12Vdc 60W DALI dimmable LED driver, active PFC function
57.00 VAT excl.
£68.40 VAT incl.
60W Constant Voltage DALI dimmable LED driver for 12Vdc LED lights and moving sign applications
- Built-in active PFC function
- Dimming range: 0.1-100%
You can order online 24/7, all ordered goods will be dispatched as soon as possible and we will notify you via e-mail. For custom made orders please contact us.
Orders over £500 (excl. VAT) Standard and Next Day service apply to UK mainland and Northern Ireland only. All orders will be sent by a trackable method.
You have the right to cancel your online website order within 14 calendar working days of ordering, or 14 calendar days of receipt of the goods (whichever is the longer).
DALI dimmable LED driver, active PFC function 60W
Model: ELED-60-12D
Dimming range: 0.1-100%
Output DC voltage: 12V
Rated current: 0～5A
Voltage accuracy: ±0.5V
Rated power: 60W
Min. load: 6W
Input Voltage Range: 100-265VAC
Frequency Range: 47-63HZ
Power Factor ( Typ.): PF≥0.95
Full Load Efficiency (Typ.): 83%
AC Current (Typ.): 0.36A
Leakage current: <0.7mA
Protections: Short Circuit (Hiccup mode, recovers automatically after fault condition is removed)/ Over Loading (≤120%) / / over current (<1.4*I out)
Built-in active PFC function
Cooling by free air convection
Working TEMP.: -40~+60°C
Working Humidity: 20~90%RH,non-condensing
Storage TEMP.-40～+60℃，10～95%RH
Humidity: ±0.03%/℃（0～50℃）
Vibration: 10～500Hz, 2G 10min./1 cycle, period for 60min.each along X,Y,Z axes
Safety standards: EN61347-1 EN61347-2-13
Withstand voltage: I/P-O/P:3.75KVAC
Isolation resistance: I/PO/P：100M Ohms/500VDC/25℃/70%RH
EMC Emission: Compliance to EN55015,EN61000-3-2 (≥60%load)
EMC Immunity: Compliance to EN61000-4-2,3,4,5,6,11, A light industry Level (surge 4KV)
Dimensions: 210x 70x 46mm (L*W*H)
Packing: 1.0Kg
ELED-60-12D
99 Items
Data sheet
- Type
- Constant Voltage
- Ingress Protection (IP)
- IP66
- Output
- 12VDC
- Wattage
- 60W
- Dimming Control
- DALI
- Design
- Metal case
