120W 12VDC DR120/12 Switching Power Supply for DIN Rail Mounting, Vadsbo



120W 12VDC Switching Power Supply for DIN Rail Mounting.
Built-in protection against short circuiting, overload, over-voltage with automatic reset when error is corrected.
The input voltage: 100-240VAC.

More details

20 Items


£ 44.16

More info

Part Number: DR120/12
Protection against:
-short circuit
-automatic return
Cooling: natural
Mounting: DIN rail TS-35/7.5 & TS-35/15
Insulation class:II
LED indicator of power supply
Standard: EN 55, 61, 50, 60, UL60950
Input voltage: 100-240VAC
Output voltage: 12VDC
Voltage tolerance: +-2%
Rated current: 10A
RAted power: 120W
Max ripple: 80 mV p-p
DC adjustment: +-10%
Efficiency: 80%
Overload capacity: 5%
Insulation level: 3kVAC
Working temp.: -10*C-+45*C
Dimensions(without DIN mount): 65x126x100mm
Weight: 670g
Modules: 4

Obvious areas include all types of operating equipment.
DR power supplies also specially suitable to drive LED stripes. To dim stripes, use Vadsbo's LED dimmer PWM360A (V-4036020PWMA).
